Dell Precision 3260 Compact Workstation
- Brand : Dell
- Form Factor : Tower
- Model : Precision 3260 Compact Workstation
- Processor : Intel Core i7-13700 (13th Gen)
- Operating System : Windows 11 Pro
- Memory Size : 16 GB
- CPU : 2.1 to 5.2 GHz Performance 8-Core, 1.5 to 4.1 GHz Efficiency 8-Core
- GPU : NVIDIA T1000 with 4 GB GDDR6 VRAM
- Memory Speed : 4800 MHz DDR5
- Optical Drive : None
- Ports : 2 x USB-A 3.1/3.2 Gen 2, 3 x USB-A 3.0 / 3.1/3.2 Gen 1
- USB-C : 1 x USB 3.2 Gen 2x2
- Display : 3 x DisplayPort Output
- Total Drive Bays : 2 x 2.5/3.5" (Internal)
- SSD Slots : 1 x M.2
- Total Installed Capacity : 512 GB
- Solid State Storage : 1 x 512 GB M.2 NVMe PCIe
- Audio I/O : 1 x 1/8" / 3.5 mm Headphone/Microphone Input/Output, 1 x 1/8" / 3.5 mm Line Input/Output
- Built-In Speakers : None
- Ethernet : 1 x RJ45 (Gigabit)
- Wi-Fi : Wi-Fi 6E (802.11ax) with MU-MIMO Support
- Keyboard : USB Full-Size Keyboard
- Pointing Device : USB Mouse
- Power Supply : 240 W with IEC
- Color : Black
- Dimensions : 7.48 x 7.01 x 2.83" / 19 x 17.81 x 7.19 cm
- Weight : 3.02 lb / 1.37 kg
Dell Precision 7865 Tower Workstation
- Brand : Dell
- Form Factor : Tower
- Model : Precision 7865 Tower Workstation
- Processor : AMD Ryzen Threadripper PRO 5945WX
- Chipset : AMD WRX80
- Operating System : Windows 11 Pro (64-Bit)
- Memory Size : 32 GB
- CPU : 4.1 to 4.5 GHz 12-Core
- GPU : NVIDIA T400 with 4 GB GDDR6 VRAM
- Memory Speed : 3200 MHz DDR4
- PCI Expansion : 2 x PCIe 4.0 x16, 2 x PCIe 4.0 x8
- Optical Drive : 8x-Speed Tray-Load SuperMulti DVD Burner with Dual Layer Support
- Ports : 5 x USB-A 3.0 / 3.1/3.2 Gen 1
- USB-C : 5 x USB 3.1/3.2 Gen 2
- Display : 3 x Mini DisplayPort 1.2 Output
- Total Drive Bays : 2 x 2.5/3.5" (Internal)
- SSD Slots : 1 x M.2 2230, 2280 PCIe 4.0 x4 (In Use), 1 x M.2 2230, 2280 PCIe 4.0 x4 (Available)
- Total Installed Capacity : 1 TB
- Solid State Storage : 1 x 1 TB M.2 NVMe PCIe
- Audio I/O : 1 x 1/8" / 3.5 mm Headphone/Microphone Input/Output, 1 x 1/8" / 3.5 mm Line Output
- Built-In Speakers : 1
- Ethernet : 1 x RJ45 (10GbE), 1 x RJ45 (Gigabit)
- Wi-Fi : Wi-Fi 6E (802.11ax); Tri-Band (2.4, 5, & 6 GHz)
- Bluetooth : 5.3
- Keyboard : 104-Key Wireless Full-Size Keyboard with Number Pad
- Pointing Device : USB Mouse, Wireless Mouse
- Power Supply : 1350 W with IEC
- AC Input Power : 90 to 264 VAC, 50 / 60 Hz at 16 A
- Operating Temperature : 50 to 95°F / 10 to 35°C
- Color : Black
- Dimensions : 17.74 x 16.45 x 6.94" / 450.6 x 417.83 x 176.28 mm
- Weight : 48.28 lb / 21.9 kg
Dell Precision 5720 32 GB RAM All in One Workstation
- Processor : Intel Xeon Processor E3-1200 v6 Family 7th generation Intel Core i7, i5
- Brand Name: Dell
- Series: Precision
- Item model number: SBR08
- Hardware Platform: PC
- Operating System: Windows 10 Professional
- Item Weight: 37.3 pounds
- Product Dimensions: 24.6 x 3.1 x 17.1 inches
- Item Dimensions L x W x H: 24.6 x 3.1 x 17.1 inches
- Processor Brand: Intel
- Processor Count: 1
- Computer Memory Type: DDR4 SDRAM
- Flash Memory Size: 1000.0
- Hard Drive Rotational Speed: 7200 RPM
- Optical Drive Type: DVD+RW
- Screen Size: 27 inches
- Max Screen Resolution: 3840x2160 pixels
- RAM: 32 GB DDR4
- Memory Speed: 2400 MHz
- Hard Drive: 1000 GB Hybrid Drive
- Graphics Coprocessor: AMD Radeon Pro WX 7100
- Chipset Brand: AMD
- Card Description: Integrated
- Graphics Card Ram Size: 2 GB
- Wireless Type: 802.11ac
- Number of USB 2.0 Ports: 2
- Number of USB 3.0 Ports: 5
Dell Precision 3431 Desktop Workstation
- Brand Name: Dell
- Processor : 9th generation Intel Core i9, i7, i5, i3, and Pentium
- RAM: SDRAM DDR4
- Memory Speed: 2666 MHz
- Hard Drive: mechanical_hard_drive
- Graphics Coprocessor: Integrated Video Card
- Chipset Brand: Intel
- Number of USB 2.0 Ports: 4
- Series: T3430
- Item model number: SBR22
- Operating System: Windows 10 Professional
- Item Weight: 14.4 pounds
- Product Dimensions: 11.5 x 3.7 x 11.4 inches
- Item Dimensions L x W x H: 11.5 x 3.7 x 11.4 inches
- Color: Black
- Processor Count: 1
- Flash Memory Size: 16 GB
- Hard Drive Rotational Speed: 7200.00
- Optical Drive Type: DVD±RW
- Power Source: AC
Dell Precision 3430 Small Form Factor Workstation
- Processor: 8032
- RAM: SDRAM DDR4
- Memory Speed: 2666 MHz
- Hard Drive: mechanical hard drive
- Graphics Coprocessor: Integrated Video Card
- Chipset Brand: Intel
- Number of USB 2.0 Ports: 4
- Brand Name: Dell
- Series: T3430
- Item model number: SBR22
- Operating System: Windows 10 Professional
- Item Weight: 14.4 pounds
- Product Dimensions: 11.5 x 3.7 x 11.4 inches
- Item Dimensions L x W x H: 11.5 x 3.7 x 11.4 inches
- Color: Black
- Processor Count: 1
- Flash Memory Size: 16 GB
- Hard Drive Rotational Speed: 7200.00
- Optical Drive Type: DVD±RW
- Power Source: AC
New Precision 3630 Tower workstation
- Available with Windows 10 Pro - for a smooth, versatile PC experience.
- Professional performance
Blaze past limits: Power through intensive tasks thanks to the latest 8th generation Intel Core and Xeon Processors and faster memory speeds of up to 2666MHz 64GB. - Expandable and flexible: Scalable storage featuring SATA, SAS and PCIe NVMe SSDs can be configured for up to 14TB delivering top performance for complex projects. Plus, Intel® Optane™ Memory massively boosts your system’s responsiveness while keeping high capacity storage costs to a minimum.
- Ready for VR
- Prepare yourself for impressive VR in the surprisingly affordable Precision 3630 Tower. Next generation AMD Radeon™ Pro and NVIDIA® Quadro® professional graphics with up to 225W of graphics support handles VR content creation with workstation-class performance you can count on.
- Prepare yourself for impressive VR in the surprisingly affordable Precision 3630 Tower. Next generation AMD Radeon™ Pro and NVIDIA® Quadro® professional graphics with up to 225W of graphics support handles VR content creation with workstation-class performance you can count on.
- Reliability when you need it most
Work without fail: When there’s no margin for error, Dell Reliable Memory Technology (RMT) Pro protects your work from potential crashes. Dell’s exclusive, RMT Pro works in conjunction with ECC memory to detect and quarantine memory errors in real time. - Independent Software Vendor (ISV) certification: Precision Workstations are tested to ensure the high
- Ready for VR
Prepare yourself for impressive VR in the surprisingly affordable Precision 3630 Tower. Next generation AMD Radeon™ Pro and NVIDIA® Quadro® professional graphics with up to 225W of graphics support handles VR content creation with workstation-class performance you can count on. - Reliability when you need it most
Work without fail: When there’s no margin for error, Dell Reliable Memory Technology (RMT) Pro protects your work from potential crashes. Dell’s exclusive, RMT Pro works in conjunction with ECC memory to detect and quarantine memory errors in real time. - Independent Software Vendor (ISV) certification: Precision Workstations are tested to ensure the high-performance applications you rely on every day run smoothly. Dell ISV-certifications cover the most popular independent software applications
Dell Precision 7920 Tower workstation
- Processor :
One or two Intel Xeon processor Scalable family CPUs with up to 28 cores per processor and Intel Advanced Vector Extensions, Intel Trusted Execution Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro technology - Operating System (Dell recommends Windows 10 Pro.) :
Windows 10 Pro (64 bit)
Enterprise Linux 7.3
Ubuntu Linux 16.04
NeoKylin 6.0 SP3 (China only) - Chipset :
Intel C621 (Lewisburg) - Memory :
Six channel memory up to 1.5TB 2667MHz DDR4 ECC memory with dual CPUs, up to 3TB with select CPU SKUs
24 DIMM Slots (12 DIMMs per CPU). Note: memory speed is dependent on specific Intel Xeon Processor Scalable processor installed - Video Card :
Support for 4 PCI Express x16 Gen 3 graphics cards, 1 - up to 750W with maximum of 3 x 250W double width graphics cards in 3 slots (dual CPU configuration) and up to 2 x 375W cards 220VAC input supply recommended for 750W configurations and some restrictions apply - High end 3D cards:
Radeon Pro WX 9100
Radeon Pro SSG (future)
NVIDIA Quadro GP100
NVIDIA Quadro P6000
NVIDIA Quadro P5000 - Mid-range 3D cards:
Radeon Pro WX 7100
Radeon Pro WX 5100
Radeon Pro WX 4100
NVIDIA Quadro P4000
NVIDIA Quadro P2000 - Entry 3D cards:
Radeon Pro WX 3100
Radeon Pro WX 2100
NVIDIA Quadro P1000
NVIDIA Quadro P600
NVIDIA Quadro P400 - Professional 2D cards:
NVIDIA NVS 310 - Hard Drive :
Front accessible FlexBays support up to 4 x 2.5”/3.5” SATA HDD/SSDs and up to 8 drives with rear FlexBays populated with integrated Intel SATA controller.
Up to 10 x 2.5”/3.5” SATA/SAS drives requires the Broadcom MegaRAID 9460-16i controller.
Up to 4 front accessible (hot plug) M.2 NVMe PCIe SSDs in FlexBays on enabled PCIe chassis with integrated Intel controller (>2 drives requires dual CPUs. NVMe RAID 0,1 option (Intel RSTe vROC).
Dell M.2 carrier with PCIe SSD for PCIe FlexBay available as customer kit.
Up to 8 x M.2 NVMe PCIe SSDs via 2 x Dell Ultra Speed Drive Quad x16 cards (maximum requires dual CPUs), NVMe RAID 0,1,10 option on 1st card (Intel RSTe vROC).
M.2 NVMe PCIe SSDs
Up to 8* x 1TB drives on 2 Dell Precision Ultra-Speed Drive Quad x16 cards. *Requires dual CPU config.
Front FlexBay M.2 NVMe PCIe SSDs
Up to 4* x 1TB drives, 2 drives per CPU. *Requires dual CPU config.
2.5” SATA SSD
Up to 10 x 1TB drives
2.5” SAS SSD
Up to 10 x 800GB drives
3.5” SAS 7200 RPM 12Gb/s
Up to 10 x 4TB
2.5” SAS 10K RPM 12Gb/s
Up to 10 x 1.8TB
2.5” SAS 15K RPM 12Gb/sUp to 10 x 900GB 2.5” Self Encrypting Drives512GB 2.5” SED (OPAL/ FIPS (140-2) HDDM.2 PCIe SED SSD512GB and 1TB - Chassis :
Bays: (4) FlexBays and (1) 5.25” FlexBay supporting up to 10 x 3.5” or 2.5” drives (with MegaRAID 9460i-16 controller)
(1) Slimline optical bay option adjacent to 5.25” bay; Available 2nd 5.25” bay – consumes/converts 2 FlexBays, (1) SD slot UHS ll Class 3 with read only support (SW enabled). Available PCIe chassis with PCIe FlexBays supporting M.2 NVMe PCIe SSDs and future U.2 NVMe PCIe SSDs. PCIe FlexBay customer kit available - Ports Front :
2 USB 3.1 Type A
2 USB 3.1 Type C
1 Universal Audio Jack
Up to 4 PCIe slots in PCIe enabled chassis for M.2 and U.2 (future) PCIe SSDs - Internal :
1 USB 2.0
1 USB 2.0 header. (requires 3rd party splitter cable to support 2 x USB 2.0 Type A ports)
8 SATA 6Gb/s plus 1 SATA for optical - Rear :
6 USB 3.1 Type A
1 Serial
2 RJ45 Network
2 PS2
1 Audio Line out
1 Audio Line in/Microphone - Security :
Trusted Platform Module (TPM 2.0); Optional CAC/PIV card reader for slimline bay, chassis Intrusion switch; Setup/BIOS Password; I/O Interface Security; Kensington lock slot, Padlock ring, lockable power supply; Optional hard drive locking sleds (key lock), Dell Data Guardian, Dell Endpoint Security Suite Enterprise. - Dimensions :
Height: 433 mm (17.05) X Width: 218 mm (8.58) X Depth: 566 mm (22.28) Starting weight: 20.4kg (45.0 lb) - Slots :
All slots PCIe Gen 3:
2 PCIe x16
2 Additional x16 slots with 2nd CPU
1 PCIe x8 open ended
1 x16 wired as x 4
1 x16 wired as x1
Dell Precision 7820 Tower workstation
- Processor :
One or two Intel Xeon processor Scalable family CPUs with up to 28 cores per processor and Intel Advanced Vector Extensions, Intel Trusted Execution Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro technology - Operating System (Dell recommends Windows 10 Pro.) :
Windows 10 Pro (64 bit)
Red Hat Enterprise Linux 7.3
Ubuntu Linux 16.04
NeoKylin 6.0 SP3 (China only) - Chipset :
Intel C621 (Lewisburg) - Memory :
Six channel memory up to 384GB 2667MHz DDR4 ECC memory with dual CPUs, 12 DIMM Slots(6 DIMMs per CPU).
Note: Memory speed is dependent on specific Intel Xeon Processor Scalable Family processor installed. - Video Card :
Support for 2 PCI Express x16 Gen 3 graphics cards1 - up to 500W with maximum of 2 x 250W double width graphics cards on single CPU configurations. Up to 2 x 150W single width graphics cards on dual CPU configurations. - High end 3D cards:
Radeon Pro WX 9100
Radeon Pro SSG (future)
NVIDIA Quadro GP100
NVIDIA Quadro P6000
NVIDIA Quadro P5000 - Mid-range 3D cards:
Radeon Pro WX 7100
Radeon Pro WX 5100
Radeon Pro WX 4100
NVIDIA Quadro P4000
NVIDIA Quadro P2000 - Entry 3D cards:
Radeon Pro WX 3100
Radeon Pro WX 2100
NVIDIA Quadro P1000
NVIDIA Quadro P600
NVIDIA Quadro P400 - Professional 2D cards:
NVIDIA NVS 310
NVIDIA NVS 315 - Hard Drive :
Front accessible FlexBays support up to 4 x 2.5”/3.5” SATA HDD/SSDs and up to 6 x 2.5” and 5 x 3.5” drives with 5.25” bay populated.
Up to 2 front accessible (hot plug) M.2 NVMe PCIe SSDs are supported in FlexBays on enabled PCIe chassis with integrated Intel controller.
NVMe RAID 0,1 option (Intel RSTe vROC). Dell M.2 carrier with PCIe SSD for PCIe FlexBay available
as customer kit.
Up to 4 x M.2 NVMe PCIe SSDs via 1 x Dell Ultra-Speed Drive Quad x16 card. NVMe RAID 0,1,10 option (Intel RSTe vROC)
M.2 NVMe PCIe SSDs
Up to 4 x 1TB drives on 1 Dell Precision Ultra-Speed Drive Quad x16 cards.
Front FlexBay M.2 NVMe PCIe SSDs
Up to 2 x 1TB drives
2.5” SATA SSD
Up to 6 x 1TB drives
2.5” SAS SSD
Up to 6 x 800GB drives
3.5” SAS 7200 RPM 12Gb/s
Up to 5 x 4TB
2.5” SAS 10K RPM 12Gb/s
Up to 6 x 1.8TB
2.5” SAS 15K RPM 12Gb/s
Up to 6 x 900GB
2.5” Self Encrypting Drives
512GB 2.5” SED (OPAL/ FIPS (140-2) HDD
M.2 PCIe SED SSD
512GB and 1TB Intel - Communications :
Integrated: Intel i219 Gigabit Ethernet controllers with Intel Remote Wake UP, PXE and Jumboframes support
Optional: Intel i210 10/100/1000 single port PCIe (Gen 3 x1) gigabit network card, Intel X550 T2 10GbE dual port PCIe (Gen 3 x4) network card, Aquantia AQN 108 2.5Gbit/5Gbe single port PCIe (Gen3 x4) network card - Chassis :
Bays: (2) FlexBays and (1) 5.25” FlexBay (can support 1 x 3.5” or 2 x 2.5” HDD/SSD drives as factory option or customer kit)
(1) Slimline optical bay; (1) SD slot UHS ll Class 3 with read only support (SW enabled).Available PCIe chassis with PCIe FlexBays supporting M.2 NVMe PCIe SSDs and future U.2 NVMe PCIe SSDs. PCIe FlexBay customer kit available - Ports Front :
2 USB 3.1 Type A
2 USB 3.1 Type C
1 Universal Audio Jack
Up to 2 (future 4) PCIe slots in PCIe enabled chassis for M.2 and U.2 (future) PCIe SSDs - Internal :
1 USB 2.0
1 USB 2.0 header. (requires 3rd party splitter cable to support 2 USB 2.0 Type A ports)
8 SATA 6Gb/s plus 1 SATA for optical - Rear :
6 USB 3.1 Type A
1 Serial
1 RJ45 Network
2 PS2
1 Audio Line out
1 Audio Line in/Microphone - Security :
Trusted Platform Module (TPM 2.0); Optional CAC/PIV card reader for slimline bay, chassis Intrusion switch; Setup/BIOS Password; I/O Interface Security; Kensington lock slot, Padlock ring, lockable power supply; Optional hard drive locking sleds (key lock), Dell Data Guardian, Dell Endpoint Security Suite Enterprise - Dimensions ;
Height: 417.9 mm (16.45) X Width: 176.5 mm (6.95) X Depth: 518.3 mm (20.41). Optional (19) rackmount rail kit.
Starting weight: 35.1 lb (15.9kg) - Slots :
All slots PCIe Gen 3
2 PCIe x16
1 PCIe x16 wired as x8
1 PCie x16 wired as x4
1 PCIe x16 wired as x1
1 PCI 32/33
Dell Precision 5820 Tower Workstation
- Processor :
Intel Xeon Processor W Family CPUs (Skylake W) with up to 10 cores per processor and Intel Advanced Vector Extensions, Intel Trusted Execution Technology, Intel AES New instructions, Optimized Intel Turbo Boost and optional Intel vPro technology - Operating System (Dell recommends Windows 10 Pro.) :
Windows 10 Pro for Workstations (upto 4 Cores Plus) English
Windows 10 Pro for Workstations (4 Cores Plus) English
Windows 7 Professional (includes Windows 10 Pro for Workstations License, up to 4 Cores) English
Windows 7 Professional (includes Windows 10 Pro for Workstations License, up to 4 Cores) English
Windows 7 Professional (VLA includes Windows 10 Pro for Workstations, upto 4 Cores) English
Windows 7 Professional (VLA includes Windows 10 Pro for Workstations, 4 Cores Plus) English
Red Hat Enterprise Linux WS v7.3 with 5 YR RHN
Red Hat Enterprise Linux WS v7.3 with 3 YR RHN
Red Hat Enterprise Linux WS v7.3 with 1 YR RHN
Ubuntu Linux 16.04,FI,WW - Chipset :
Intel C422 (Kaby Lake W) - Memory :
Four channel memory up to 256GB 2666MHz DDR4 ECC memory. 8 DIMM slots
Note: Memory speed is dependent on specific Intel Xeon Processor W Family processor installed - Video Card :
Support for 2 PCI Express x16 Gen 3 graphics card2 - up to 600W with maximum of up to 2 x 300W double width graphics cards. - High end 3D cards:
Radeon Pro WX 9100
Radeon Pro SSG (future)
NVIDIA Quadro GP100
NVIDIA Quadro P6000
NVIDIA Quadro P5000 - Mid-range 3D cards:
Radeon Pro WX 7100
Radeon Pro WX 5100
Radeon Pro WX 4100
NVIDIA Quadro P4000
NVIDIA Quadro P2000 - Entry 3D cards:
Radeon Pro WX 3100
Radeon Pro WX 2100
NVIDIA Quadro P1000
NVIDIA Quadro P600
NVIDIA Quadro P400 - Professional 2D cards:
NVIDIA NVS 310
NVIDIA NVS 315 - Hard Drive :
Front accessible FlexBays support up to 4 x 2.5”/3.5” SATA HDD/SSDs and up to 6 x 2.5” and 5 x 3.5” drives with 5.25” bay populated.
Up to 2 front accessible (hot plug) M.2 NVMe PCIe SSDs are supported in FlexBays on enabled PCIe chassis with integrated Intel controller.
NVMe RAID 0,1 option (Intel RSTe vROC). Dell M.2 carrier with PCIe SSD for PCIe FlexBay available
as customer kit.
Up to 4 x M.2 NVMe PCIe SSDs via 1 x Dell Ultra-Speed Drive Quad x16 card. NVMe RAID 0,1,10 option (Intel RSTe vROC).
M.2 NVMe PCIe SSDs
Up to 4 x 1TB drives on 1 Dell Precision Ultra-Speed Drive Quad x16 cards.
Front FlexBay M.2 NVMe PCIe SSDs
Up to 2 x 1TB drives
2.5” SATA SSD
Up to 6 x 1TB drives
2.5” SAS SSD
Up to 6 x 800GB drives
3.5” SAS 7200 RPM 12Gb/s
Up to 5 x 4TB
2.5” SAS 10K RPM 12Gb/s
Up to 6 x 1.8TB
2.5” SAS 15K RPM 12Gb/s
Up to 6 x 900GB
2.5” Self Encrypting Drives
512GB 2.5” SED (OPAL/ FIPS (140-2) HDD
M.2 PCIe SED SSD - Communications :
Optional: Intel i210 10/100/1000 single port PCIe (Gen 3 x1) gigabit network card, Intel X550 T2 10GbE dual port PCIe (Gen 3 x4) network card,
Aquantia AQN 108 2.5Gbit/5Gbe single port PCIe (Gen3 x4) network card - Chassis :
Bays: (2) FlexBays and (1) 5.25” FlexBay (can support 1 x 3.5” or 2 x 2.5” HDD/SSD drives as factory option or customer kit)
(1) Slimline optical bay; (1) SD slot UHS ll Class 3 with read only support (SW enabled)
Available PCIe chassis with PCIe FlexBays supporting M.2 NVMe PCIe SSDs and future U.2 NVMe PCIe SSDs. PCIe FlexBay customer kit available. - Ports Front:
2 USB 3.1 Type A
2 USB 3.1 Type C
1 Universal Headphone Jack
Up to 2 (future 4) PCIe slots in PCIe enabled chassis for M.2 and U.2 (future) PCIe SSDs - Internal:
1 USB 2.0
1 USB 2.0 header (requires 3rd party splitter cable to support USB 2.0 Type A ports)
8 SATA 6Gb/s plus 1 SATA for optical - Rear:
6 USB 3.1 Type A
1 Serial
1 RJ45 Network
2 PS2
1 Audio Line out
1 Audio Line in/Microphone - Dimensions :
Height: 417.9 mm (16.45) X Width: 176.5 mm (6.94) X Depth: 518.3 mm (20.40)
Starting weight: 15.4kg (34.0 lbs) - Slots :
All slots PCIe Gen 3
2 PCIe x16
1 PCIe x16 wired as x8
1 PCie x16 wired as x4
1 PCIe x16 wired as x1
1 PCI 32/33
