Servers & Workstations Models

• Brand : Dell
• Form Factor : 2U rack server
• Model : PowerEdge R740xd Rack Server
• Socket : Two Socket Server
• Processor : Up to two Intel Xeon Scalable processors, up to 28 cores per processor
• Operating System: Canonical Ubuntu LTS Citrix XenServer, SUSE Linux Enterprise Server VMware ESXi
• Memory : 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666, 3TB max, Up to 12 NVDIMM, 192 GB Max, Supports registered ECC DDR4 DIMMs only
• Storage Controllers : Internal controllers: PERC H330, H730p, H740p, Software RAID (SWRAID) S140
• Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB
• External PERC (RAID): H840
• 12Gbps SAS HBAs (non-RAID): External- 12Gbps SAS HBA (non-RAID), Internal- HBA330 (non-RAID)
• Drive Bays:
• Front bays: Up to 24 x 2.5” SAS/SSD/NVMe, max 153TB Up to 12 x 3.5” SAS, max 120TB
• Mid bay: Up to 4 x 3.5” drives , max 40TB Up to 4 x 2.5” SAS/SSD/NVMe, max 25TB
• Rear bays: Up to 4 x 2.5” max 25TB, Up to 2 x 3.5” max 20TB
• Dimensions : Form factor: Rack (2U)
• Max depth: 715.5 mm
• Data Protection : TPM 1.2/2.0 optional Cryptographically signed firmware, Secure Boot, System Lockdown, Secure erase
• Ports: Network daughter card options: 4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE
• Front ports: VGA, 2 x USB 2.0, dedicated IDRAC Direct Micro-USB
• Rear ports: VGA, Serial, 2 x USB 3.0, dedicated iDRAC network port
• Video card: VGA, Up to 8 x Gen3 slots, Up to 4 x16
• Chassis : Optional LCD or Security bezel
• Power : Titanium 750W, Platinum 495W, 750W, 1100W, 1600W, and 2000W, 48VDC 1100W, 380HVDC 1100W, 240HVDC 750W, Hot plug power, supplies with full redundancy Up to 6 hot plugs fans with full redundancy High performance fans available
• Management : Embedded / At-the-Server: iDRAC9 with Lifecycle Controller (Express, Enterprise), iDRAC Direct, iDRAC REST API with Redfish, Quick Sync 2 BLE/wireless module
• Consoles : OpenManage Enterprise, OpenManage Essentials, OpenManage Power Center
• Mobility : OpenManage Mobile
• Tools : iDRAC Service Module, OpenManage Server Administrator, OpenManage Storage Services, Dell EMC Repository Manager, Dell EMC System Update, Dell EMC Server Update Utility, Dell EMC Update Catalogs

• Brand : Dell
• Form Factor : Rack
• Model : PowerEdge R540 Bronze Rack Server
• Socket : Two Socket Server
• Processor : Intel Xeon Bronze 3204 1.92GHz, 6Core/6T, 9.6GT/s, 8.25MB Cache, No Turbo, No HT (85Watts) Processor
• Max Memory : 16 DIMMS
• Memory : 1 x 8GB RDIMM
• Max HDD Scalability : Up to 8, 3.5in Hot Plug Hard Drives and Software RAID
• HARD DISK : 1 x 1TB 7.2K RPM SATA 6Gbps 512n 3.5in Hot-plug Hard Drive
• RAID InBuilt : SW RAID
• POWER SUPPLY : Single, Hot-Plug Power Supply, 495Watts
• System Management : iDRAC9,Enterprise
• WARRANTY : 3 Years ProSupport and Next Business Day Onsite

• Brand : Dell
• Model : PowerEdge C5000 Chassis
• Maximise data centre floor space with the 3U PowerEdgeâ„¢ C5000 chassis. Shared infrastructure for up to 12 PowerEdge C microservers enhances server density and helps lower power and cooling costs.

• Brand : Dell
• Model : PowerEdge C6145 AMD Processor-based 2U Rack Server
• Get fast answers to tough problems with the PowerEdgeâ„¢ C6145, with two 4-socket AMD Opteronâ„¢ 6200 processor-based servers in 2U.

• Brand : Dell
• Model : PowerEdge C8000XD Storage Node
• Maximize data center storage flexibility with up to four double-wide, hot-swap PowerEdgeâ„¢ C8000XD storage nodes in one 4U C8000 Series chassis.

• Brand : Dell
• Model : PowerEdge C8220X Compute GPU Node
• Maximize data center computing density with up to four double-wide, hot-swap PowerEdgeâ„¢ C8220X compute GPU nodes in one 4U C8000 Series chassis.

• Brand : Dell
• Model : PowerEdge R6525 8 Core Rack Server
• Chassis
  Form Factor:
  10U modular enclosure holds up to sixteen half-height blade servers
  44.0cm(17.3”)H x 44.7cm(17.6”)W x 75.4cm(29.7”)D
• Weight:
  Empty Chassis only – 98lbs (44.5kg)
  Chassis w/ all rear modules (IOMs, PSUs, CMCs, KVM) - 176lbs (79.8kg)
  Max Fully loaded w/ blades and rear modules - 394lbs (178.7kg)
• Cooling Fans:
  M1000e Chassis comes standard with 9 hot pluggable, redundant fan modules

Based on Energy Smart Technologies, M1000e fans are a breakthrough in power and cooling efficiency.
The fans deliver low power consumption, but also use next generation “low flow” technology to ensure the
lowest possible amount of fresh air is consumed to cool the enclosure

• Input Devices:
  Front Control Panel with interactive Graphical LCD
• Supports initial configuration wizard :
  Local server blade, enclosure, and module information and troubleshooting

Two USB Keyboard/Mouse connections and one Video connection (requires the optional Avocent iKVM switch
to enable these ports) for local front “crash cart” console connections that can be switched between blades
Power Up to six 3000W high-efficiency power supplies, six 2700W high-efficiency power supplies or up to six -48V DC 2700W power supplies.

Based on Dell’s Energy Smart technologies, the M1000e power supplies deliver greater levels of efficiency, even at low levels of utilization. Supported power supply

• configurations include:
  3+3 and 2+2 (grid redundancy)
  2+1, 3+1, 4+2, and 5+1 (power supply redundancy)
  2+0 and 3+0 (non-redundant mode)

The M1000e chassis supports dynamic power supply engagement (DPSE) mode, which if enabled, puts lightly loaded power supplies into standby mode, driving up the utilization and the efficiency of the active supplies. Dell supports either 110–120V or 208–240V AC power supply input and supports a wide range of power distribution options. Dell recommends 208–240V AC for all production environments.
Storage

• External Storage Options:
  For information about Dell external storage options, visit Dell.com/Storage.
  Management
• 1 (standard) or optional 2nd (redundant) Chassis Management Controller(s) (CMC) that provide:
  Single secure interface for inventory, configuration, monitoring, and alerting for the chassis and all components Multi-chassis management capability allows up to nine chassis and 288 servers to be managed from a single, embedded, agent-less interface

Enables automated and embedded one-to-many blade BIOS and firmware updates, independent of the OS through iDRAC
Allows one-to-many blade server BIOS capture and replication
Real-Time Power/Thermal Monitoring and Management
Real-Time System AC Power Consumption with resettable peak and minimum values
System-level power limiting and slot-based power prioritization
Manages Dynamic Power Engagement functionality that can help to lower overall system power consumption by ensuring power supplies run at their optimal efficiency points
Manages fan speed control using Dell’s enhanced efficiency technologies to ensure fans are delivering optimal cooling while minimizing power consumption and airflow

• Secure Web (SSL) and Command Line (Telnet/SSH) interfaces :
  Supports multiple levels of user roles and permissions, including integration into MicrosoftActive DirectoryServices and Lightweight Directory Access Protocol (LDAP) services for authentication 2 x 10/100/1000Mb Ethernet ports + 1 serial port

Provides single point of connection from management network to iDRAC on each of the blades and the management interfaces on the integrated I/O modules
2nd Ethernet port supports daisy chaining of CMCs for improved cable management

• Optional Integrated Avocentkeyboard, video and mouse (iKVM) switch:
  Enables USB keyboard/mouse and video port on front control panel
• Dell OpenManage™ Systems Management :
  Dell OpenManage Server Administrator—monitoring agents and 1:1 management utilities

Dell OpenManage Essentials—discover, inventory, monitor, and update M1000e chassis and bladesIntegration with third-party management solutions through Dell’s Certified Partner Program Remote Management

• Communications:
  Brocade Switch M5424
  Enclosure I/O Modules
  Up to six total I/O modules for three redundant fabrics, featuring Ethernet FlexIO Switches providing
  on demand stacking and uplink scalability.
• PowerConnect M6220 Ethernet Switch :
  Includes 4 x fixed copper 10/100/1000Mb Ethernet uplinks plus 2 of the following optional modules:
  2 x 24Gb Stacking Ports
  2 x 10Gb Optical (XFP-SR/LR) uplinks
  2 x 10Gb copper CX4 uplinks
• Standard Features include :
  Layer 3 routing (OSPF, RIP, VRRP)
  IPv6 support
  Layer 2/3 QoS
  Access Control Lists
• Dell Ethernet Pass-Through Module :
  Supports 16 x 10/100/1000Mb copper RJ45 connections
  Only Ethernet Pass-through module on the market that supports full range of 10/100/1000Mb operation
• BrocadeM4424 SAN I/O Module :
  Access Gateway Mode or FC Switch
  Access Gateway Mode enables NPIV functionality on external ports which delivers enhanced fabric interoperability, simplified set up, and doesn’t consume an FC domain

12 or 24 port versions with 4 or 8 x FC 1/2/4Gb SFPs respectively :
4Gb Fibre Channel Pass-Through Module
16 x FC 1/2/4Gb SFP ports

• Brand : Dell
• Form Factor : Rack
• Model : EMC PowerEdge M640 Modular Blade Server
• Processor :
  Up to two Intel Xeon Scalable processors, up to 28 cores per processor
• Memory1 :
  16 DIMMs in total; Supports RDIMM /LRDIMM/AEP
  Up to 6 channels with 2 DPC / 1 DPC / 1 DPC
  Up to two 2.5” NVME PCIe SSD
  DDR4 speeds up to 2666 MT/s 16 x 32GB RDIMM
  Storage Controllers
• Internal controllers:
  Software RAID S140, PERC9 H330, H730P
• Boot Optimized Storage Subsystem:
  HWRAID 2 x M.2 SSDs 120GB, 240 GB
  Internal Dual SD Module optional
• Drive Bays Front:
  Up to 2 x 2.5” SAS/SATA (HD/SSD) max 12.8TB
  Power Supplies
  2700W and 3000W for M1000e
  1100W and 1600W for VRTX
• Fans :
  Hot plug fans with full redundancy
  Dimensions
  Chassis depth:
  544.32 mm (handle push-in), 564.87 mm (Handle pull out)
  Embedded Management
  Chassis Management Controller (CMC)
  IPMI 2.0 compliant
  Integrated Dell Remote Access Controller (iDRAC 9) with Lifecycle Controller
  OpenManage Software
  OpenManage Essentials (OME)
  OpenManage Server Administrator (OMSA)
  I/O and Ports
  Network daughter card options
  2 x 10GE + 4 X 1GE, 4 x 10GE
• Front ports:
  Power button
  System ID / Status LED
  1 USB 2.0 MicroAB port with iDRAC management function
  1 USB 3.0 port
• Rear ports:
  2 x PCIe 3.0 (x8) mezzanine cards for M1000e
  2 x PCIe 2.0 (x8) switch mezzanine cards for VRTX
• Video card:
  VGA controller integrated with iDRAC
  8 Gen3 low-profile cards for VRTX
  3 standard height, full-length x8 PCIe Gen2 cards for VRTX
  5 low profile, half-length x8 PCIe Gen2 cards for VRTX
  Supported Operating Systems
  Canonical Ubuntu Server LTS
  Citrix XenServer (optional)
  Microsoft Windows Server
  Microsoft Windows Server with Hyper-V™
  Red Hat Enterprise Linux
  SUSE Linux Enterprise Server
  VMware vSphere
  VMware ESXi
• Recommended Support :
  Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information
  Management
  Embedded / At-the-Server
  iDRAC9 with Lifecycle Controller (Express, Enterprise)
  iDRAC Direct
  iDRAC REST API with Redfish
  Chassis Management Controller (CMC)
• Consoles :
  OpenManage Enterprise
  OpenManage Essentials
  OpenManage Power Center
• Mobility :
  OpenManage Mobile
• Tools :
  iDRAC Service Module
  OpenManage Server Administrator
  OpenManage Storage Services
  Dell Repository Manager
  Dell System Update
  Dell Server Update Utility
  Dell Update Catalogs
• OpenManage Integrations :
  Microsoft System Center
  VMware vCenter
  BMC software (available from BMC)
• OpenManage Connections :
  Nagios Core and Nagios XI
  HPE Operations Manager i (OMi)

• Brand : Dell
• Form Factor : Rack
• Model : EMC PowerEdge VRTX Chassis
• Product Configurations :
  Microsoft Windows Server 2008 SP2, x64, x86
  Microsoft Windows Server 2008 R2, SP1
  Microsoft Windows Server 2012
  Microsoft Windows Server 2012 R2
  Microsoft Windows Server 2016
  Novell SUSE Linux Enterprise Server
  Red Hat Enterprise Linux
  VMware vSphere ESXi
  VMware vCenter Server 6.5
  Also supports Microsoft Exchange, Microsoft SQL Server and Microsoft SharePoint Server
• Drive Bays :
  Up to 12 x 8.8cm (3.5) NLSAS, SAS, or SAS SSD hot-plug drives or
  Up to 25 x 6.3cm (2.5) NLSAS, SAS, or SAS SSD hot-plug drives
  Optional FIPS 140-2 certified self-encrypting drives (SED)
• Integrated Ethernet Switch :
  Internal 1GbE 8-port pass-through module
  Internal 1GbE 24-port switch
  Internal 10GbE switch
• GPU :
  Up to 2 single-wide actively cooled GPU accelerators (NVIDIA Quadro P4000)
  Chassis Form factors:
  Tower or 5U rack enclosure
• Tower configuration:
  48.4cm (19.1) H with system feet x 31.0cm (12.2) W with system feet opened x 73.0cm (28.7) D
  Weight (empty) = 31.7kg (69.7lb)
  Weight (maximum) = 74.8kg (164.9lb)
• Rack configuration:
  21.9cm (8.6) H x 48.2cm (19.0) W x 73.0cm (28.7) D
  Weight (empty) = 24.7kg (54.5lb)
  Weight (maximum) = 68.7kg (151.5lb)
• Server node options :
  PowerEdge M520, M620, M630, M820 and M830 server nodes
  Power Redundant power supply units:
  Supports up to four 1100W or 1600W AC power supply units (PSU) in 3+1 and 2+2 redundant configurations
• Cooling :
  VRTX comes standard with six hot-pluggable, redundant fan modules and four blower modules:
  Based on Dell Energy Smart Technologies, VRTX fans and blowers are a breakthrough in power and cooling efficiency. Fans and blowers deliver low-power consumption and use next-generation fan technologies to ensure the lowest possible amount of fresh air is consumed to cool the enclosure.
• RAID Controllers :
  Single shared PERC8 with optional second redundant shared PERC8 available
• Rack Support :
  ReadyRails II sliding rails for 4-post racks with square, round, or threaded holes
  I/O Expansion Slots
• 8 flexible PCIe slots:
  3 full-height/full-length slots (150W) with double-wide card support (225W)
  5 low-profile/half-length slots (25W)
• Systems Management :
  Delivers comprehensive functionality yet simple and easy to use:
  Uses Chassis Management Controller (CMC) to manage all resources (server nodes, storage, networking, and power) with a unified management tool, presented in a single console
  Monitors up to nine VRTX chassis from a single, consolidated CMC console
• Offers both Local and Remote management :
  Is available with either Enterprise or Express CMC licensing for CMC
  Redundant Chassis Management Controller is available
  Server nodes each contain proven iDRAC7 with Lifecycle Controller for agent-free systems
  Management that are fully supported within the OpenManage product portfolio

• Brand : Dell
• Form Factor : Rack
• Model : EMC PowerEdge M830 Blade Server
• Processor :
  Intel Xeon processor E5-4600 v4 product family
• Processor Sockets:
  Internal interconnect
  2 x Intel QuickPath Interconnect (QPI); 6.4 GT/s; 8.0 GT/s; 9.6 GT/s
• Cache :
  2.5MB per core; core options: 6, 10, 12, 14, 16, 18, 22
• Operating System :
  Microsoft Windows Server 2008 R2
  Microsoft Windows Server 2012
  Microsoft Windows Server 2012 R2
  Microsoft Windows Server 2016
  Novell SUSE Linux Enterprise Server
  Red Hat Enterprise Linux
  VMware ESX
• Optional hypervisors:
  Citrix XenServer
  VMware vSphere ESXi
• Chipset :
  Intel C610 series chipset
• Memory1 :
  Up to 3TB (48 DIMM slots): 4GB/8GB/16GB/32GB/64GB DDR4 up to 2400 MT/s
  Embedded Hypervisor (Optional)
  VMware vSphereESXi using redundant internal SD cards dedicated for hypervisor
• Storage :
  Hot-plug hard drive options: PowerEdge Express Flash NVMe PCIe SSD, SATA HDD/SSD or SAS HDD/SSD
• Drive Bays :
  12 x 1.8” SSD, 4 x 2.5” SATA HDD/SSD or SAS HDD/SSD, 2 x 2.5” PCIe SSD and 2 x 2.5” SATA HDD/SSD or SAS HDD/SSD
• I/O Mezzanine Card Options :
  Broadcom 5719 quad-port 1Gb NIC
  Broadcom 5720 dual-port 1Gb NIC
  Broadcom 57810 dual-port 10Gb DA/SFP+ CNA
  Broadcom 57810 dual-port 10Gb Base-T network adapter
• RAID Controllers :

           PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P

• Communications :
  Two Dell Select Network Adapters using:
  Broadcom 5720 1Gb Quad Port KR Blade Network Daughter Card
  QLogic 57840S 10Gb Quad Port KR Blade Network Daughter Card
  QLogic 57810S-k Dual port 10Gb KR Blade Network Daughter Card
  Emulex OneConnect OCm14102-U4-D, Dual Port 10GbE, KR CNA Network Daughter Card
  Emulex dual-port 10GB KR Blade Network Daughter Card
  Intel i350 Quad Port 1 Gigabit, KR Blade Network Daughter Card
  Intel x520-k dual-port 10Gb KR Blade Network Daughter Card
• Power :
  Chassis level – PowerEdge M1000e 2700W Platinum and 3000W Titanium PSU options
• Video Card :
  Video type Matrox G200 (integrated with iDRAC8)
  Video memory: 16MB shared with iDRAC8 application memory
• Chassis :
  Form factor: Full-height blade with up to 8 nodes in a M1000e chassis; up to 2 nodes in VRTX converged infrastructure
• Blade Server Dimensions:
  Height: 197.92 mm (15.2 inch)
  Width: 50.35 mm (2 inch)
  Depth: 564.9 mm (19.2 inch)
• Management :
  Systems management:
  IPMI 2.0 compliant
  Dell OpenManage Essentials
  Dell OpenManage Mobile
  Dell OpenManage Power Center
  Remote management iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade)
  8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
• Dell OpenManage Integrations:
  Dell OpenManage Integration Suite for MicrosoftSystem Center
  Dell OpenManage Integration for VMwarevCenter
• Dell OpenManage Connections:
  HP Operations Manager, IBM TivoliNetcooland CA Network and Systems Management
  Dell OpenManage Plug-in for OracleDatabase Manager
