Dell PowerEdge R640 Rack Server - Dell Servers|Dell Poweredge Rack Servers
Dell PowerEdge R640 Rack Server
- Brand : Dell
- Form Factor : 1U rack server
- Model : PowerEdge R640 Rack Server
- Socket : Two Socket Server
- Processor : Up to two Intel Xeon Scalable processors, up to 28 cores per processor
- Operating System : Canonical Ubuntu LTS, Citrix XenServer, SUSE Linux Enterprise Server, VMware ESXi, 24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2666, 3TB max, Up to 12 NVDIMM, 192 GB Max, Supports registered ECC DDR4 DIMMs only
- Storage Controllers : Internal controllers: IPERC H330, H730p, H740p, Software RAID (SWRAID) S140
- Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB
- External PERC (RAID): H840
- 12Gbps SAS HBAs (non-RAID): Internal- HBA330 (non-RAID)
- Drive Bays Front drive bays: Up to 10 x 2.5” with up to 8 NVMe, SAS/SATA/SSD/NVMe, max 58TB, Up to 4 x 3.5” SAS/SATA, max 48TB
- Rear drive bays: Up to 2 x 2.5” SAS/SATA/SSD/NVMe, max 12TB
- Dimensions : Rack (1U)
- Chassis depth : 705.05 mm
- Data Protection : TPM 1.2/2.0 optional Cryptographically signed firmware, Hot-plug hard drives, Secure Boot, System Lockdown, Internal Dual SD Module, Secure erase
- Ports Network daughter card options: 4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE
- Front ports: Video, 1 x USB 2.0, available USB 3.0, dedicated IDRAC Direct USB
- Rear ports: Video, serial, 2 x USB 3.0, dedicated iDRAC network port
- Video card: VGA, NVIDIA NVS310 available as PCIe card Up to 3 x Gen3 slots, all x16
- Chassis : Optional LCD or Security bezel
- Power : Titanium 750W, Platinum 495W, 750W, 1100W, and 1600W, 48VDC 1100W, 380HVDC 1100W, 240HVDC 750W, Hot plug power supplies with full redundancy option Up to 8 hot plugs fans with full redundancy
- Management : Embedded / At-the-Server, iDRAC9 with Lifecycle Controller (Express, Enterprise), iDRAC Direct, iDRAC REST API with Redfish, Quick Sync 2 BLE/wireless module
- Consoles : OpenManage Enterprise, OpenManage Essentials, OpenManage Power Center
- Mobility : OpenManage Mobile
Rs. 1/-*
For Further Details
