dell server price chennai

dell powervault jbod expansion storages - Latest dell powervault jbod expansion storages Models

Dell Storage MD1400 Direct Attached Storage dealers price chennai, hyderabad, andhra, telangana, secunderabad, tamilnadu, india
Dell Storage MD1400 Direct Attached Storage
  • Connectivity
  • Unified mode (single path) for daisy chaining of up to 8 enclosures per PERC H830 or PERC H840 (4 enclosures per port, single path)
  • Unified mode (recommended redundant path) for daisy chaining up to 4 enclosures per PERC H830 or PERC H840 (4 enclosures connected to both ports via redundant path
  • cabling)
  • Connectivity per EMM:
  • 4 mini-SAS HD connector for connection to the host or expansion
  • Service management:
  • USB mini b connector (for factory use only)
  • Dimensions & Weight
  • Height x width x depth:
  • MD1400: 8.7 cm (3.43") x 48.2 cm (18.98") x 59.2 cm (23.3") (depth includes PSU handle)
  • MD1420: 8.7 cm (3.43") x 48.2 cm (18.98") x 53.9 cm (21.22") (depth includes PSU handle)
  • Weight: 28.59 kg (63.03 lb) (maximum configuration)
  • 9.0 kg (19.8 lb ) (empty)
  • Environmental Operating Conditions
  • (A)Temperature
  • Operating: 10° to 35°C (50° to 95°F) with maximum temperature gradation of 10°C per hour
  • Storage: -40° to 65°C (-40° to 149°F) with temperature gradation of 20°C per hour
  • (B)Relative Humidity:
  • Operating: 8% to 85% (non-condensing) with maximum humidity gradation of 10% per hour
  • Storage: 5% to 95% (non-condensing)
  • (C)Altitude
  • Operating: -16 to 3048 m (-50 to 10,000 ft)
  • Storage: -16 to 10,600 m (-50 to 35,000 ft)
  • Expansion Capacity :
  • PERC H830/H840 HBA enables expansion to 8 enclosures, PCIe 3.0, 12Gbps SAS, dual-port, 4 ports per enclosure
  • Management
  • Enclosure Management Modules (EMM)
  • 2 EMM provide redundant enclosure management capability
  • Power
  • Wattage – also supports DC power: AC – 600W; DC – 700W
  • Host heat dissipation: AC – 2047 BTU/hr; DC – 2388 BTU/hr
  • Input voltage range: 100-240 VAC, auto-sensing; 48 V DC
  • Frequency range:50/60 Hz
  • Amperage:8.6 A at 100 V, 4.3 A at 240 V
  • Supported continuous consumption:
  • Up to 1.2 A at +5V
  • Up to 0.5 A at +12V
  • RAID
  • RAID levels 0, 1, 5, 6, 10, 50 and 60
  • Rack Support
  • Dell ReadyRails™ II static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded-hole racks
  • Storage
  • (A)Drive type
  • 3.5" and 2.5" SAS, NL-SAS, SSD, SED (2.5” available with adapter)
  • (B)Maximum Raw Capacity (per enclosure)
  • Up to 144TB when using 12 x 10TB NL-SAS 3.5" HDDs
Dell Storage MD1280 Dense Enclosure Storage dealers price chennai, hyderabad, andhra, telangana, secunderabad, tamilnadu, india
Dell Storage MD1280 Dense Enclosure Storage
  • Chassis : 5U, 84 hot-pluggable 3.5 drive bays
  • Connectivity : 6GB SAS
  • Environmental Operating Conditions :
  • (A)Temperature
  • Operating: 10° t 35°C (50° to 95°F) with maximum temperature gradation of 20°C per hour
  • Non-operating: -40° to 65°C (-40° to 149°F) at a maximum altitude of 12,000 m (39,370ft)
  • (B)Relative humidity:
  • Operating: 10% to 80% (non-condensing) with 29° C (82.4°F) maximum dewpoint.
  • Non-operating: 5% to 95% (non-condensing) with 33°C (91°F) maximum dewpoint.
  • (C)Altitude
  • Operating: -16 to 3048 m (-50 to10,000 ft)
  • Storage: -16 to 10,600 m (-50 to 35,000 ft)
  • (D)Maximum Usable Capacity :
  • Up to 1.3PB when using 2 enclosures, maximum of 168 8TB HDDs
  • Management
  • Server dependent
  • Power
  • Wattage: 2800 AC only
  • Input voltage range: 200-240 VAC
  • Frequency range: 50/60 Hz
  • RAID Controllers
  • 2 Enclosure Management Modules (EMM) provide redundant enclosure management capability
  • Scalability
  • Up to 672TB when using 84 x 8TB NL-SAS 3.5" HDDs
  • Storage
  • Drive performance and capacity:
  • 3.5 NL-SAS 6Gb HDD (7.2K): 4TB, 6TB
  • 3.5 NL-SAS 4kn 6Gb HDD (7.2k): 6TB
  • 3.5 NL-SAS 512e 6Gb HDD (7.2K): 8TB
Dell PowerVault MD1220 Storage dealers price chennai, hyderabad, andhra, telangana, secunderabad, tamilnadu, india
Dell PowerVault MD1220 Storage
  • Operating System: Refer to the PERC RAID Card details for supported Operating Systems PERC H810
  • Back-Panel Connectors :
  • (A)SAS connectors (per EMM):
  • 1 SAS (SFF 8088) "IN" connector for connection to the host
  • 1 SAS (SFF 8088) "OUT" connector for expansion to an additional enclosure
  • (B) Serial connector (per EMM):
  • 1 6-pin UART mini-DIN connector (for factory use only)
  • Chassis
  • Height: 8.7cm (3.43 inches)
  • Width: 48.2cm (18.98 inches)
  • Depth: 54.1 (21.30 inches)
  • Weight: 23.31 kg (51 lb) (maximum configuration)
  • 8.61 kg (19 lb) (empty)
  • Connectivity :
  • Support for the following configurations:
  • (A)Unified mode (single path) for daisy chaining of up to 8 enclosures per PERC H810 (4 enclosures per port, single path)
  • (B)Unified mode (redundant path) for daisy chaining up to 4 enclosures per PERC H810 (4 enclosures connected to both ports via redundant path cabling)
  • (C)Split mode with dual Enclosure Management Modules providing direct connectivity to drives 0 through 11 and a separate connectivity to drives 12 through 23
  • Environmental Operating Conditions :
  • (A)Temperature
  • Operating: 10° to 35°C (50° to 95°F) with maximum temp gradation of 10°C per hour
  • Storage: -40° to 65°C (-40° to 149°F) with temp gradation of 20°C per hour
  • Supports Fresh Air cooling, up to 35 degrees Celsius
  • (B)Relative humidity
  • Operating: 8% to 85% (non-condensing) with maximum humidity gradation of 10% per hour
  • Storage: 5% to 95% (non-condensing)
  • (C)Altitude
  • Operating: -16 to 3048 m (-50 to 10,000 ft)
  • Storage: -16 to 10,600 m (-50 to 35,000 ft)
  • LED Indicators :
  • (A)Front panel
  • 1 two-color LED indicator for system status
  • 2 single-color LED indicators for power and split mode
  • (B)Hard-drive carrier
  • 1 single-color activity LED
  • 1 two-color LED status indicator per drive
  • (C)EMM
  • 3 two-color LED status indicators: one for each of the EMM SAS ports and one for the EMM status
  • 1 single-color Unit Identification LED for each EMM
  • (D)Power supply/cooling fan module
  • 3 LED status indicators for Power supply/cooling fan fault, AC power, and DC power
  • Management : Enclosure Management Modules (EMM): 2 EMM modules provide redundant enclosure management capability
  • Power : Two fully redundant power supplies; supports DC power
  • (A)Wattage: AC - 600 W; DC - 700 W
  • (B)Heat dissipation: AC - 2047 BTU/hr; DC - 2388 BTU/hr
  • (C)Voltage: 100-240VAC; 48V DC
  • (D)Frequency: 50/60Hz
  • (E)Amperage: 8.6 A at 100 V, 4.3 A at 240 V
  • (F)Available Hard Drive Power (per slot)
  • Supported drive power consumption (continuous):
  • up to 1.2 A at +5V
  • up to 0.5 A +12V
  • RAID : PERC H800 supports RAID levels 0, 1, 5, 6, 10, 50 and 60.
  • See PERC H800 server compatability matrix for a list of currently supported servers
  • Storage :
  • (A)Drives:
  • Up to twenty-four (24) 2.5-inch hot-pluggable SAS Hard Disk Drives (HDDs) at 7.2K, 10K, 15K rpm and SAS Solid State Drives (SSDs).
  • (B)Drive performances and capacities
  • (I)2.5” 6Gbps SAS:
  • HDD 15K – 146GB, 300GB, 600GB
  • HDD 10K – 300GB, 600GB, 900GB, 1.2GB
  • HDD 10K 512e – 1.8TB
  • HDD 7.2K – 500GB, 1TB
  • SSD – 200GB, 800GB value SLC
  • SSD – 400GB mainstream SLC
  • SSD – 800GB RI MLC
  • SSD – 200GB, 400GB WI SLC
  • SSD – 2TB eMLC
  • (II)2.5” 12Gbps SAS
  • HDD 15K – 600GB
  • HDD 7.2K NL-SAS 512e – 2TB
  • SSD – 200GB, 400GB, 800GB 1.6TB MU MLC
  • SSD – 200GB, 400GB, 800GB WI MLC
  • SSD – 800GB, 1.6TB RI MLC
  • (C)Maximum Capacity (per enclosure)
  • Up to 48TB when using 24 x 2TB NL-SAS 2.5" HDDs
  • (D)Expansion Capabilities
  • PERC H810 enables expansion to 8 enclosures, 4 per port
Dell PowerVault MD1200 Storage dealers price chennai, hyderabad, andhra, telangana, secunderabad, tamilnadu, india
Dell PowerVault MD1200 Storage
  • Operating System: Refer to RAID Card for details on supported Operating Systems PERC H810
  • SAS connectors (per EMM): 1 SAS (SFF 8088) IN connector for connection to the host, 1 SAS (SFF 8088) OUT connector for expansion to an additional enclosure
  • Serial connector (per EMM): 1 6 pin UART mini-DIN connector (for factory use only)
  • Chassis Height : 8.7cm (3.43 inches)
  • Chassis Width : 48.2cm (18.98 inches)
  • Chassis Depth : 59.4 (23.39 inches)
  • Chassis Weight : 28.39 kg (62.6 lb) (maximum configuration)8.84 kg (19.5 lb) (empty)
  • SAS connectors (per EMM):  1 SAS (SFF 8088) IN connector for connection to the host, 1 SAS (SFF 8088) OUT connector for expansion to an additional enclosure
  • Serial connector (per EMM):1 6-pin UART mini-DIN connector (for factory use only)
  • Connectivity:
  • (A)Unified mode (single path) for daisy chaining of up to 8 enclosures per PERC H810 (4 enclosures per port, single path)
  • (B)Unified mode (redundant path) for daisy chaining up to 4 enclosures per PERC H810 (4 enclosures connected to both ports via redundant path cabling)
  • (C)Split mode with dual Enclosure Management Modules providing direct connectivity to drives 0 through 5 and a separate connectivity to drives 6 through 11.
  • Environmental Operating Conditions:
  • (A)Temperature:
  • Operating: 10° to 35°C (50° to 95°F) with maximum temp gradation of 10°C per hour
  • Storage: -40° to 65°C (-40° to 149°F) with temp gradation of 20°C per hour
  • Supports Fresh Air cooling, up to 35 degrees Celsius
  • (B)Relative humidity:
  • Operating: 8% to 85% (non-condensing) with maximum humidity gradation of 10% per hour
  • Storage: 5% to 95% (non-condensing)
  • (C)Altitude:
  • Operating: -16 to 3048 m (-50 to 10,000 ft)
  • Storage: -16 to 10,600 m (-50 to 35,000 ft)
  • LED Indicators :
  • (A)Front panel
  • 1 two-color LED indicator for system status
  • 2 single-color LED indicators for power and split mode
  • (B)Drive carrier
  • 1 single-color activity LED
  • 1 two-color LED status indicator per drive
  • (C)EMM
  • 3 two-color LED status indicators: one each for the two EMM SAS ports and one for the EMM status
  • 1 single-color Unit Identification LED for each EMM
  • (D)Power supply/cooling fan module
  • 3 LED status indicators for power supply status, power supply/fan fault and AC status
  • Management :
  • 2 Enclosure Management Modules(EMM) provide redundant enclosure management capability
  • Power :
  • Two fully redundant power supplies; supports DC power
  • Wattage: AC - 600 W; DC – 700 W
  • Heat dissipation: AC - 2047BTU/hr; DC - 2388 BTU/hr
  • Voltage: 100-240 VAC, auto sensing; 48V DC
  • Frequency: 50/60 Hz
  • Amperage: 8.6 A at 100 V, 4.3 A at 240 V
  • Available Drive Power (per slot)
  • Supported drive power consumption (continuous):
  • up to 1.16 A at +5V
  • up to 1.6 A +12V
  • RAID : PERC H800 supports RAID levels 0, 1, 5, 6, 10, 50 and 60.
  • Storage :
  • (A)Drives :
  • Up to twelve (12) hot-pluggable SAS Hard Disk Drives (HDDs) at 7.2K, 10K and 15K rpm and SAS Solid State Drives (SSDs)
  • (B)Drive performances and capacities :
  • (I)3.5” 6Gbps SAS:
  • HDD 15K – 300GB, 450GB, 600GB
  • HDD 7.2K – 1TB, 2TB, 3TB, 4TB
  • HDD 7.2K NL-SAS 512e – 6TB
  • (II)3.5” 12Gbps SAS:
  • HDD 7.2K NL-SAS 512e – 6TB, 8TB, 10TB
  • (III)2.5” 6Gbps SAS with 3.5” carrier:
  • HDD 10K – 300GB, 600GB, 900GB, 1.2TB
  • HDD 10K 512e– 1.8TB
  • SSD – 400GB mainstream SLC
  • SSD – 200GB, 800GB value SLC
  • SSD – 800GB RI MLC
  • SSD – 200GB, 400GB WI SLC
  • (IV)2.5 12Gbps SAS with 3.5 carrier: 7.2K HDD NL-SAS 512e 2TB, SSD 200GB, 400GB, 800GB, 1.6TB MU MLC
  • SSD – 200GB, 400GB, 800GB WI MLC
  • SSD – 800GB, 1.6TB RI MLC
  • (C)Maximum Capacity (per enclosure): Up to 120TB when using 12 x 10TB NL-SAS 3.5 HDDs
  • (D)Expansion Capabilities: PERC H810 Host RAID adapter enables expansion to 8 enclosures (4 enclosures per port)
