Dell EMC PowerEdge M640 Modular Blade Server - Dell Dell Servers|Dell Poweredge Blade Servers

Dell EMC PowerEdge M640 Modular Blade Server chennai, hyderabad

Dell EMC PowerEdge M640 Modular Blade Server

  • Processor :
    Up to two Intel Xeon Scalable processors, up to 28 cores per processor
  • Memory1 :
    16 DIMMs in total; Supports RDIMM /LRDIMM/AEP
    Up to 6 channels with 2 DPC / 1 DPC / 1 DPC
    Up to two 2.5” NVME PCIe SSD
    DDR4 speeds up to 2666 MT/s 16 x 32GB RDIMM
    Storage Controllers
  • Internal controllers:
    Software RAID S140, PERC9 H330, H730P
  • Boot Optimized Storage Subsystem:
    HWRAID 2 x M.2 SSDs 120GB, 240 GB
    Internal Dual SD Module optional
  • Drive Bays Front:
    Up to 2 x 2.5” SAS/SATA (HD/SSD) max 12.8TB
    Power Supplies
    2700W and 3000W for M1000e
    1100W and 1600W for VRTX
  • Fans :
    Hot plug fans with full redundancy
    Dimensions
    Chassis depth:
    544.32 mm (handle push-in), 564.87 mm (Handle pull out)
    Embedded Management
    Chassis Management Controller (CMC)
    IPMI 2.0 compliant
    Integrated Dell Remote Access Controller (iDRAC 9) with Lifecycle Controller
    OpenManage Software
    OpenManage Essentials (OME)
    OpenManage Server Administrator (OMSA)
    I/O and Ports
    Network daughter card options
    2 x 10GE + 4 X 1GE, 4 x 10GE
  • Front ports:
    Power button
    System ID / Status LED
    1 USB 2.0 MicroAB port with iDRAC management function
    1 USB 3.0 port
  • Rear ports:
    2 x PCIe 3.0 (x8) mezzanine cards for M1000e
    2 x PCIe 2.0 (x8) switch mezzanine cards for VRTX
  • Video card:
    VGA controller integrated with iDRAC
    8 Gen3 low-profile cards for VRTX
    3 standard height, full-length x8 PCIe Gen2 cards for VRTX
    5 low profile, half-length x8 PCIe Gen2 cards for VRTX
    Supported Operating Systems
    Canonical Ubuntu Server LTS
    Citrix XenServer (optional)
    Microsoft Windows Server
    Microsoft Windows Server with Hyper-V™
    Red Hat Enterprise Linux
    SUSE Linux Enterprise Server
    VMware vSphere
    VMware ESXi
  • Recommended Support :
    Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information
    Management
    Embedded / At-the-Server
    iDRAC9 with Lifecycle Controller (Express, Enterprise)
    iDRAC Direct
    iDRAC REST API with Redfish
    Chassis Management Controller (CMC)
  • Consoles :
    OpenManage Enterprise
    OpenManage Essentials
    OpenManage Power Center
  • Mobility :
    OpenManage Mobile
  • Tools :
    iDRAC Service Module
    OpenManage Server Administrator
    OpenManage Storage Services
    Dell Repository Manager
    Dell System Update
    Dell Server Update Utility
    Dell Update Catalogs
  • OpenManage Integrations :
    Microsoft System Center
    VMware vCenter
    BMC software (available from BMC)
  • OpenManage Connections :
    Nagios Core and Nagios XI
    HPE Operations Manager i (OMi)

Call for Best Price...!


For Further Details
